MPPS v18 Diagnostic Interface

We offer a professional diagnostic interface MPPS v18 – a tool for modifying FLASH memory in engine control units (ECU). It allows for increased power, torque, and the removal of the DPF filter.

The interface works on most computers with a USB port. MPPS v18 supports many types of controllers, including:

• M3.8
• M5.9
• ME7.xx
• MED9
• Marrelli (with additional functions in the ECU)
• MED17
• EDC15 / EDC16 / EDC17
• Delphi
• Siemens
• Delco
• Sagem
• Trionic
• ...and many others

The interface is compatible with Windows 7 and Windows 10 systems (both 32- and 64-bit). The software is available in multiple languages, including Polish.

List of Supported Models

To check the full list of supported controllers, visit the link below (copy and paste it into your browser):

https://ccy.pl/img/200232/lista.pdf

What is Chiptuning?

Chiptuning is the electronic enhancement of engine power by modifying settings in its controller (ECU). This improves the car's performance – the vehicle becomes faster, more dynamic, and in many cases, also more economical.

Car manufacturers leave a certain power reserve that is not utilized in factory settings. Every car is equipped with an ECU, which is a computer that controls the engine's operation under various road conditions. The default parameters are configured for maximum vehicle durability, not for its full power and torque potential.

How Does the Interface Work?

Connect the interface to the OBD2 port in the car, read the contents of the controller's memory, modify it in a dedicated program (e.g., WinOLS), and then upload it back. You can use ready-made memory maps that have been previously prepared and tested. The result is a noticeable increase in power – even by several dozen horsepower – without interfering with the vehicle's mechanics.

Example Applications:

• Power increase
• Improvement of torque and driving dynamics
• Reduction of fuel consumption
• Increase of starting dose
• Removal of maximum speed limitation
• Removal of FAP/DPF filter
• Disabling lambda sensor
• Disabling EGR/AGR valves
• Disabling swirl flaps
• Modification of DPF saturation, AdBlue correction

The interface supports, among others, DDE4 controllers in BMW cars and automatically calculates Checksum in EDC17 systems.

Additional Features of the MPPS v18 Interface

• Advanced recovery functions – in some cases, the interface can recover ECUs that other tools cannot even connect to.
• Full or partial read and write – if the controller allows, the user can choose the range of operations.
• Reading and writing speed adjustment – the ability to adjust the data transmission rate.
• Writing “changes only” functions for faster programming (when supported by the ECU).
• Automatic detection of K / CAN lines – with the possibility of forcing a specific communication method.
• Temporary immobilizer bypass – allows flashing in “bench mode” in ME7 systems.
• Startup mode support – for ECUs based on C167 and ST10 processors.
• EEprom support – the ability to read and write EEprom data in selected controllers.
• TPROT level check – for VAG MEDC17 ECUs, without the need to open the controller.

STARTUP MODE HANDLING MODULE FOR CONTROLLERS WITH TRICORE PROCESSOR

• Automatic detection of ECU and processor type – the entire process takes place without user intervention.
• Reading and writing EEPROM, IROM, XROM memory – where possible and supported by the ECU.
• OBD TPROT patch – allows flashing of ECUs with active TPROT protection (currently only VAG units are supported).
• Checking TPROT / DS activity – without the need to open the controller.
• Support for Bosch controllers – up to TP12 security level inclusive.
• Support for Siemens controllers – in versions without password protection.
• Unlocking VAG Simos PCR and Simos 8 controllers
• Automatic checksum correction – for Bosch MEDC17 controllers.

Reading and Writing Micro, Flash, and EEPROM Without BDM Programmer

The interface allows operation without the need for a BDM programmer – safely, quickly, and through the diagnostic connector.

• Fiat 6F3 – read/write Micro, Flash, and EEPROM via K-line and CAN
• Fiat 6JF – read/write Micro and EEPROM via K-line
• Fiat 8DF – read/write Micro and EEPROM via K-line
• Fiat 8F2 – read/write Micro and EEPROM via K-line and CAN
• Fiat 8F3 – read/write Micro and EEPROM via K-line and CAN
• Fiat 8GM – read/write Micro and EEPROM via CAN
• Fiat 8GS – read/write Micro and EEPROM via CAN
• Fiat 5SF3 – read/write Flash and EEPROM via CAN and separately EEPROM via K-line
• Fiat 5SF8 – read/write Flash and EEPROM via K-line and CAN
• Fiat 5SF9 – read/write Flash and EEPROM via CAN
• Fiat ME7.9.10 – read/write Micro via CAN
• Fiat ME7.6.3 – read/write Micro via CAN
• Opel 6O2 – read/write Micro, Flash, and EEPROM via K-line and CAN
• Opel 6O3 – read/write Micro, Flash, and EEPROM via K-line and CAN
• Opel 6JO – read/write Micro and EEPROM via K-line

Contents of the Set

• Chiptuning interface MPPS V18
• Cabling for connecting the device
• DVD with software, instructions, and guides
• Polish installation manual and technical support
• Database of (modified and original) files on DVD
• Free software or demo version
